Item                                                     Specification                                                Unit
Screen Size                                           2.8 inches                                                   Diagonal
Display Resolution                                 240(H) x RGB x 320(V)                                 Dot
Active Area                                           43.2 (H) x 57.6 (V)                                       mm
Outline Dimension                                 50 (H) x 69.2 (V) x 2.4 (D)                            mm
Display Mode                                        Normally white/Transmissive
Pixel Arrangement                                 RGB Vertical-Stripe
Display Color                                         262K
Viewing Direction (Gray Inversion)           12 o’clock
Driver IC                                               ILI9341 --
Input Interface                                      8080 8/16 bit parallel interface
